Diagramas Eléctricos Ford Transit 350 3.5 Turbo (2018)

Para el Diagrama eléctrico FORD TRANSIT 350 V6-3.5L TURBO 2018 se incluyen los siguientes componentes:

Engine Control Module (ECM).
Exterior Lights.
Interior Lights.
Headlights.
Instrument Cluster/Tablero de Instrumentos.
Mirrors.
Power Windows.
Shift Interlock.
Sound Systems.
Starting Charging – Charging Circuit.
Starting Charging – Starting Circuit.
Sipplemental Restraints (SRS).
Transmissions Controls.
Transmissions.
Air Conditioning.
Anti-lock Brakes/ Frenos Antibloqueo (ABS).
Body Control Modules/ Módulos de Control del Cuerpo del vehículo (BCM).
Computer Data Lines/ Computadoras del auto (pin data automotriz).
Auxiliary Fuse panel.
Auxiliary Jucntion Box.
Connector Auxiliary Junction Box.
Battery Junction Box.
Brake Pedal Position Sensor.
Camshaft Position Sensor / Sensor de posición del árbol de levas (CMP).
Data Link Connector/ Conector de Enlace de Datos (DLC).
Fuel Injector.
Fuse And Relay Information Body Control Module.
Knock Sensor/Fuel Tank Pressure Sensor.
High Current Battery Junction Box.
Ignition Coil.
Manifold Absolute Pressure Sensor.
Heated Oxygen Sensor/ Sensor de Oxígeno (HO2S).
Intake Air Temperature Sensor/Ambient Air Temperature.
Powertrain Control Module (PCM).
Throttle Position Sensor/Accelerator Pedal Position Sensor.
