Diagramas Eléctricos Ford Focus 2.0 (2015)

Para el Diagrama eléctrico FORD FOCUS 2.0L 4 CIL 2015 se incluyen los siguientes componentes:

Engine Control Module.
Starting Charging – Charging Circuit.
Starrting Charging – Starting Circuit.
Body Computer – Except Electric.
Computer Data Lines/ Computadoras del auto (pin data automotriz).
Defogger.
Exterior Lights.
Interior Lights.
Headlights.
Instrument Cluster/Tablero de Instrumentos
Mirrors.
Power Windows.
Sound Systems.
Shift Interlock.
Transmission Range (TR) Sensor.
Transmission – Electric.
Transmissions – Except Electric.
Anti-Lock Brakes/ Frenos Antibloqueo (ABS).
Air Conditioning.
Ambient Air Temperature (AAT) Sensor.
Battery Junction Box (BJB).
Camshaft Position Sensor / Sensor de posición del árbol de levas (CMP).
Crankshaft Position Sensor / Sensor de posición del cigüeñal (CKP).
Data Link Connector/ Conector de Enlace de Datos (DLC).
Engine Coolant Temperature Sensor /Sensor de temperatura del refrigerante (ECT).
Heated Oxygen Sensor/ Sensor de Oxígeno (HO2S).
High Current Battery Junction Box (BJB).
Intake Air temperature sensor/ Sensor de temperatura del aire (IAT).
Knock Sensor/ Sensor de golpeteo (KS).
Manifold Absolute Pressure (MAP) Sensor.
Mass Air Flow & Intake Air Temperature Sensor.
Park Reverse Neutral Position Switch.
Rear Junction Box (RJB).
Universal Heated Oxygen Sensor.
Wheel Speed Sensor (WSS).
Powertrain Control Module.
