Diagramas Eléctricos Ford Explorer 4wd 4.0l (2004)

Para el Diagrama eléctrico FORD EXPLORER 4WD V6-4.0L VIN E 2004 se incluyen los siguientes componentes:

Engine Control Module (ECM).
Starting Charging – Charging Circuit.
Starting Charging – Starting Circuit.
Information Bus – Computer Data Lines/ Computadoras del auto (pin data automotriz).
Cruise Control.
Defogger.
Exterior Lights.
Headlights.
Horns.
Instrument Cluster/Tablero de Instrumentos.
Interior Lights.
Mirrors.
Power Windows.
Supplemental Restraints (SRS).
Sound Systems.
Shfit Interlock.
Transmissions – 4WD Circuit.
Transmissions – A/T Circuit.
Anti-lock Brakes/ Frenos Antibloqueo (ABS).
Air Conditioning.
Accelerator Pedal Position Sensor / Sensor de posición del pedal (APP).
Camshaft Position Sensor / Sensor de posición del árbol de levas (CMP).
Crankshaft Position Sensor / Sensor de posición del cigüeñal (CKP).
Cylinder – Head Temperature Sensor.
Data Link Connector/ Conector de Enlace de Datos (DLC).
Digital Transmission Range (DTR).
Engine Coolant Temperature Sensor /Sensor de temperatura del refrigerante (ECT).
Heated Oxygen Sensor/ Sensor de Oxígeno (HO2S).
Intermediate Shaft Speed (OSS).
Powertrain Control Module (PCM).
Throttle Position Sensor / Sensor de posición del acelerador (TPS).
Turbine Shaft Speed (TSS) Sensor.
LF Front Wheel Speed Sensor.
Rear Wheel Speed Sensor – Right Front.
Wheel Speed Sensor.
Knock Sensor/ Sensor de golpeteo (KS).
Passenger Compartment Fuse Panel – Central Junction Box (CJB).
Battery Junction Box (BJB) Power Distribution Box.
Auxiliary Relay Box (Vehicles Equipped W/4×4)
Rear Relay Box.
