Diagramas Eléctricos Ford Explorer 4wd 4.0l (2002)

Para el Diagrama eléctrico FORD EXPLORER 4WD V6-4.0L VIN E 2002 se incluyen los siguientes componentes:

Engine Control Module (ECM).
Starting Charging – Charging Circuit.
Starting Charging – Starting Circuit.
Body Computer
Computer Data Lines/ Computadoras del auto (pin data automotriz).
Exterior Lights.
Interior Lights.
Headlights.
Instrument Cluster/Tablero de Instrumentos.
Mirrors.
Power Windows.
Supplemental Restraints (SRS).
Sound SYstems.
Shift Interlock.
Transmissions – 4WD Circuit.
Transmissions – A/T Circuit.
Anti-lock Brakes/ Frenos Antibloqueo (ABS).
Air Conditioning.
auxiliarry Junction Box (AJB).
Battery Junction Box (SJB).
Crankshaft Position Sensor / Sensor de posición del cigüeñal (CKP).
Data Link Connector/ Conector de Enlace de Datos (DLC).
Digital Transmission Range Sensorr.
Early Build, Central Junction Box (CJB).
Engine Coolant Temperature Sensor /Sensor de temperatura del refrigerante (ECT).
Engine Temperature Sensor.
Heated Oxygen Sensor/ Sensor de Oxígeno (HO2S).
Idle Air Control Actuator.
Knock Sensor/ Sensor de golpeteo (KS).
Late Build, Central Junction Box (CJB).
Mass Air Flow Meter Sensor / Sensor de flujo de masa de aire (MAF).
Passenger Compartment.
Rear Relay Box.
Throttle Position Sensor / Sensor de posición del acelerador (TPS).
Wheel Speed Sensor.
Powertrain Control Module.
